Used 1974 EX-CELL-O 74-A | LAPPING MACHINES

                                                                                                 74-A EXCELLO MODEL CENTER LAPPING MACHINE

                                                                                                                 S/N 74107    Year: 1974

STANDARD SPECIFICATIONS
Maximum diameter of work.................... 10"
Maximum length of work...................... 36"
Maximum diameter of centers................. 15/16"
Maximum diameter of lapping stone........... 1"
Lapping stone shank size.................... 1/2"
Distance – center to column................. 5 1/4"
Lapping spindle speeds........... 665, 1280, 2300, 4300 RPM
Maximum stroke of lapping spindle........... 1 1/2"
Maximum stroke of dressing diamond.......... 1 1/4"
Vertical adjustment of dresser.............. 1 1/2"
Motor............................ 1 HP / 1800 RPM
Overall height.............................. 68"
Floor space................................. 20 1/2" x 26"
Approximate weight.......................... 1,500 lbs.

Machine is equipped with dresser, motor and electrical controls.

Specifications are deemed accurate, however, subject to verification or prior sale.
