1CFN HEALD NOTCH BORE

1CFN90 HEALD NOTCH BORE

S/N 48514 Year:1981

STANDARD CATALOG SPECIFICATIONS
Maximum outside diameter of work..............4 1/2
Minimum outside diameter of work..............7/8
Maximum length of work........................2
Maximum swivel of work........................30 Degrees
Center of wheel spindle from floor............40

SPEEDS FEEDS
Table travel (total including run-out)........ 8
Wheel wear compensation on diameter...........0 - .004
Work speeds.(std).... 266, 366,487, 804, 1105 1473 RPM
High force(adjustable)....................... 30 - 300 Lbs.

DRIVE POWER REQUIREMENTS
Backing plate motor...........................1/2 HP @ 520 RPM
Wheel head motor for belt drive............... 10 HP @ 3600 RPM
Hydraulic pump motor..........................2 HP @ 1800 RPM
Coolant pump motors(2)....................... 3/4 HP 1/2 HP

GENERAL DATA
Overall height................................95 1/2
Length width of base on floor...............68 x 49
Floor space (without coolant tank)............ 91 x 79
Floor space (with coolant tank)............... 109 x 79
Net weight of machine(approximate)........... 10,500#

EQUIPMENT FEATURES
Auto-loading unloading.
Rotary diamond dresser.

� Machine is used to make a notch in the bearing rale to insert the final ball.

Specifications are deemed accurate, however, subject to verification or prior sale.
