Used 1958 CINCINNATI #1 MICROCENTRIC | GRINDERS, CHUCKING

#1 CINCINNATI MICROCENTRIC GRINDER

S/N 2T1H5F-66

STANDARD CATALOG SPECIFICATIONS
Capacity, work diameter range, grind............... .5 to 4.5"

WHEEL HEAD ADJUSTMENTS
Rapid advance movement: Maximum.................... 1.5"
Minimum.................... .187"

MAXIMUM INFEED MOVEMENT
Dual rate, standard................................ .06"
Infeed rate, (rate/min)............................ .005 to 1"
Tarry adjustment, seconds.......................... .6 to 12

HEAD STOCK ADJUSTMENTS
Swivel plate: With auto loader..................... 0 30 Deg.
With out auto loader................. 0 45 Deg.
Head stock movement parallel to swivel plate....... 4.75"
Vertical movement on eccentric roller under cross slide..................... 5"
Longitudinal movement of head stock with cross slide screw.................. 7.5"
Total sub slide movement perpendicular to cross slide movement, plain....... 4.87"

GRINDING WHEELS
"A" Type wheel head: Maximum diameter.............. 20"
Minimum diameter.............. 15"

WORKPIECE WIDTH GRIND
20" Wheel, 8,500 SFPM.............................. 3"
20" Wheel, 12,000 SFPM............................. 1.87"
24" Wheel, 8,500 SFPM.............................. 2.25"

MOTORS AND DRIVE
Grinding wheel head:8,500 SFPM..................... 10 HP
12,000 SFPM.................... 10/20 HP
Head stock, vee arc................................ 1.5 HP
Head stock, RPM, Infinitely variable............... 200 2000
Hydraulic pump..................................... 3 HP

CUTTING FLUID SYSTEM
Pump capacity...................................... 30 GPM
Tank capacity, gallons............................. 41.5
Pump drive......................................... .25 HP

WEIGHT Domestic shipping, approximate.............. 13,000 lbs.

EQUIPMENT & FEATURES
Double arm loader.
Magnetic shoe work head drive.
Conjugate double angle dresser with auto diamond advance.

Specifications are deemed accurate, however, subject to verification or prior sale.
