CINCINNATI #2 OM 2M2H1Y-479

#2 OM CINCINNATICENTERLESS GRINDER

STANDARD CATALOG SPECIFICATIONS

CAPACITY (Depending on which work rest is ordered,
not included in price)
Standard workrest...................... 1/16 to 3 1/2 dia.
Low thru feed workrest................. 2 to 4 3/4 dia.
Barwork................................ 1/8 to 2 dia. 18 long

GRINDING WHEEL (Not supplied)
Width.............. 4, 6, or 8 Hole............ 12
Maximumdiameter................................... 20
Minimumdiameter................................... 14

REGULATING WHEEL (Not supplied)
Width.............. 4, 6, or 8 Hole............ 5
Maximumdiameter................................... 12
Minimumdiameter................................... 9

MOTOR DRIVES
Grindingwheel..................................... 15 HP
Regulating wheel...................................1 1/2 HP
Hydraulicpump..................................... 1 1/2 HP
Cuttingfluid...................................... 1/4 HP

OVERALL DIMENSIONS
Floor space:...................................... 53 x 86
Weight.............................................7,000 lbs.

PRIVATE tc� \l 1
EQUIPMENT FEATURES
Filmatic bearings.
Hydraulic contour truing ongrinding wheel.
Hydraulic contour truing onregulating wheel.
Grinding wheel mount forstraight side wheel.
Regulating wheel mount forstraight side wheel.

Specifications are deemed accurate, however, subjectto verification or prior sale.
