PFAUTER P900 JOB8725

                                                                                                               PFAUTER P900 GEAR HOBBER

                                                                                                                             S/N 24380

STANDARD SPECIFICATIONS
Maximum Workpiece Diameter…………………………………..35.433"
Maximum Axial Travel…………………………………………...19.685"
Worktable Diameter……………………………………………….27.559"
Workhead Spindle Bore…………………………………………...7.087"
Maximum Radial Center Distance………………………………...21.654"
Minimum Radial Center Distance…………………………………1.969"
Maximum Hob Diameter…………………………………………..7.559"
Maximum Hob Length……………………………………………..8.465"
Maximum Hob Shift Travel………………………………………..7.874"
Hob Speed Range (Inf. Variable)…………………………………..45 - 280 RPM
Rapid Traverse Radial……………………………………………...0.069 in/min
Machine Weight……………………………………………………18,739 LBS
Plant Power………………………………………………………...460 VAC, 60 Hz
Machine Dimensions (lxwxh)………………………235.433" x 114.764" x 137.795"

EQUIPPED WITH
Differential
Two-Cut Cycle
Tangential Cycle
Tailstock W/Center
Change Gears
Arbors
Chip Conveyor
Coolant System

Specifications are deemed accurate, however, subject to verification or prior sale.
